GPU workloads in Cluster API workload clusters

This guide explains how to configure and use GPU-enabled nodes in Cluster API (CAPI) workload clusters to run GPU-accelerated workloads, focusing on NVIDIA GPUs. GPU support is available starting with release v30.1.0.

Overview

GPU-accelerated computing can significantly enhance performance for specific workloads like machine learning, video processing, scientific simulations, and other compute-intensive tasks. Giant Swarm’s CAPI workload clusters support GPU nodes on AWS (CAPA) and Azure (CAPZ).

Prerequisites

• A running CAPI workload cluster
• kubectl configured to access your workload cluster

Supported cloud providers and GPU types

AWS

Giant Swarm CAPI clusters on AWS support the following Graphics Processing Unit instance types (incl. upcoming series):

• p2 family: Cost-effective GPU instances with NVIDIA K80
• p3 family: High-performance instances with NVIDIA V100
• p4 family: Latest generation with NVIDIA A100
• p5 family: Advanced performance with NVIDIA H100
• p5e family: Enhanced performance with NVIDIA H200
• g3 family: Graphics-optimized with NVIDIA Tesla M60
• g4dn family: Balanced GPU compute with NVIDIA T4
• g5 family: Latest generation graphics-optimized with NVIDIA A10G
• g6 family: Next-generation GPU instances with NVIDIA L4
• g6e family: Enhanced performance with NVIDIA L40S Tensor Core

Azure

Giant Swarm CAPI clusters on Azure support the following GPU VM families and series (incl. upcoming series):

NC-family (Compute-intensive, Graphics-intensive)

• NC series: NVIDIA K80 GPU
• NCv2 series and NCv3 series: NVIDIA P100 and V100
• NCasT4_v3 series: NVIDIA T4
• NC_A100_v4 series: NVIDIA A100
• NCads_H100_v5 series and NCCads_H100_v5 series: NVIDIA H100

ND-family (Large memory compute-intensive workloads)

• ND_A100_v4 series and NDm_A100_v4 series: NVIDIA A100
• ND-H100-v5 series: NVIDIA H100

NV-family (Visualization and rendering)

• NV series: NVIDIA M60
• NVv3 series: NVIDIA Tesla M60
• NVadsA10_v5 series: NVIDIA A10

Adding GPU nodes to your Cluster API workload cluster

Configuring a GPU node pool

To add GPU nodes to your CAPI workload cluster, you need to create a new node pool with the appropriate GPU instance type. The following example shows how to add GPU nodes to an AWS (CAPA) workload cluster.

Update your cluster app’s values to add a new node pool with GPU instances:

nodePools:
  gpu-worker-pool-1:
    # instance type with GPU
    instanceType: g5.2xlarge
    maxSize: 1
    minSize: 1
    # root volume size in GB needs to be at least 15
    rootVolumeSizeGB: 15
    instanceWarmup: 600
    minHealthyPercentage: 90
    # taints which are required for GPU workloads
    customNodeTaints:
    - key: "nvidia.com/gpu"
      value: "Exists"
      effect: "NoSchedule"

Apply the updated configuration to your cluster.

Installing the GPU Operator app

The recommended way to enable NVIDIA GPU support in your cluster is to use the GPU Operator app, which is needed for scheduling and running GPU workloads.

Install the GPU Operator app from the Giant Swarm Catalog in the kube-system namespace.

The GPU Operator app installs several components:

• NVIDIA Device Plugin
• NVIDIA MIG Manager (for A100 GPUs)
• Node Feature Discovery
• GPU Feature Discovery

We don’t install the NVIDIA driver and toolkit by the GPU Operator, because it’s already provided by default.

Verifying the installation

Verify that the GPU operator is installed and works correctly and wait for all the pods to be running:

gpu-feature-discovery-tjj65                                          1/1     Running     0          6s
gpu-operator-6d5b78c78f-f7dg8                                        1/1     Running     0          15s
gpu-operator-node-feature-discovery-gc-554ccf9b5-vzwd2               1/1     Running     0          15s
gpu-operator-node-feature-discovery-master-567bf66c77-xvsbz          1/1     Running     0          15s
gpu-operator-node-feature-discovery-worker-2lhks                     1/1     Running     0          15s
gpu-operator-node-feature-discovery-worker-jp7dm                     1/1     Running     0          15s
gpu-operator-node-feature-discovery-worker-mvq4t                     1/1     Running     0          15s
gpu-operator-node-feature-discovery-worker-pxtxq                     1/1     Running     0          15s
gpu-operator-node-feature-discovery-worker-s5zr6                     1/1     Running     0          15s
gpu-operator-node-feature-discovery-worker-xfbl7                     1/1     Running     0          15s
nvidia-dcgm-exporter-6l8vx                                           1/1     Running     0          6s
nvidia-device-plugin-daemonset-rr49p                                 1/1     Running     0          6s
nvidia-operator-validator-vjhxh                                      1/1     Running     0          7s

Running GPU workloads

To run workloads on GPU nodes, you need to request GPU resources and the runtimeClassName nvidia needs to be specified in your pod specification:

apiVersion: v1
kind: Pod
metadata:
  name: cuda-vector-add
  namespace: kube-system
spec:
  tolerations:
  - key: "nvidia.com/gpu"
    operator: "Exists"
    effect: "NoSchedule"
  # runtimeClassName is required to run GPU workloads
  runtimeClassName: nvidia
  restartPolicy: OnFailure
  containers:
    - name: cuda-vector-add
      image: "nvcr.io/nvidia/k8s/cuda-sample:vectoradd-cuda11.7.1-ubuntu20.04"
      resources:
        limits:
          nvidia.com/gpu: 1 # Requesting 1 GPU

Resource management

GPUs are only available through limits, not requests. The number specified in limits determines how many GPUs will be allocated to the pod.

Best practices

1. Taints and tolerations: Use Kubernetes taints on GPU nodes and corresponding tolerations in pod specifications to prevent non-GPU workloads from being scheduled on expensive GPU resources.

2. Resource quotas: Implement resource quotas to control GPU allocation in multi-tenant environments.

3. Node auto provisioning: Consider using Karpenter or cluster autoscaling with GPU node pools to automatically scale GPU resources based on demand.

Getting support

If you encounter issues that cannot be resolved using the troubleshooting steps above, contact Giant Swarm support with the following information:

• Output of kubectl get nodes -o wide
• Output of kubectl describe node <gpu-node-name>
• Logs from the GPU Operator pods: kubectl logs -n kube-system gpu-operator-<deployment-id>-<pod-id>

Limitations

• GPU memory overcommitment is not supported by default
• Dynamic allocation of GPU is not supported (GPU is allocated at container start time)
• Specific GPU driver versions may be required for certain CUDA applications
